Description
The Specification Of TOTOLINK X2000R AX1500 Wireless Dual Band Gigabit Router
| Interface | 4 * 10/100/1000Mbps LAN Ports 1 * 10/100/1000Mbps WAN Port |
| Power Supply | 12V DC/1A |
| Antenna | 2 * 2.4GHz fixed antennas(5dBi) 2 * 5GHz fixed antennas(5dBi) |
| LED Indicators | 1 *SYS, 1 *WAN, 4 *LAN |
| Dimensions (L x W x H) | 206 x 121 x 41mm |
| Wireless | |
| Standards | IEEE 802.11ax, IEEE 802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE 802.11a |
| RF Frequency | 2.4GHz/5GHz |
| Data Rate | 2.4GHz: Up to 300Mbps 5GHz: Up to 1201Mbps |
| EIRP | 2.4GHz <20dBm 5GHz <20dBm |
| Wireless Security | 64/128-bit WEP, WPA, WPA2 and WPA-Mixed WPA3 |
| Reception Sensitivity | – 2.4G: 11b 11M：[email protected]% PER 11g 54M：[email protected]% PER 11n HT20 MCS7：[email protected]% PER HT40 MCS7：[email protected]% PER- 5G: 11a 54M：[email protected]% PER 11n HT20 MCS7：[email protected]% PER HT40 MCS7：[email protected]% PER 11ac VHT80 MCS9：[email protected]% PER 11ax HE80 MCS11：[email protected]% PER |
| Software | |
| Basic | WAN Wireless LAN System Information |
| Network | WAN Setting LAN Setting IPTV Setting DHCP&ARP Tables Static Route Routing Table |
| Wireless | Basic Settings Guest network Advanced Settings Access Control Wireless Schedule |
| Security | IP/Port Filtering MAC Filtering URL Filtering |
| NAT | Virtual Server(Port Forwarding) – DMZ VPN Passthrough |
| Operation Mode | Gateway Mode Repeater Mode AP Mode WISP Mode |
| Other Function | Upgrade Firmware Save/Reload Settings Time Zone Settings DDNS Denial-of-Service TR-069 Config Password Settings Reboot Schedule System Log Statistics Run Command Logout |
| Others | |
| Package Contents | X2000R Wireless Router * 1 Power Adapter * 1 Ethernet Cable * 1 Quick Installation Guide * 1 |
| Environment | Operating Temperature: 0℃~40 ℃ (32 ℉~104℉) Storage Temperature: -40℃~70 ℃ (-40 ℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
| Warranty | 1 Year |
| WAN Type | Static IP, DHCP, PPPoE/Russia PPPoE, PPTP/Russia PPTP, L2TP/Russia L2TP |
| QoS | Up/Down speed control on WAN, Bandwidth control based on IP address |
TOTOLINK X2000R AX1500 Wireless Dual Band Gigabit Router
