Description
| Interface | 4*10/100Mbps LAN Ports 1*10/100Mbps WAN Port |
| Status | System Status Statistics System Log |
| Wireless | Basic Settings(including Band, Mode, SSID, Multiple APs, etc.) Security Settings Site Survey WDS Advanced Settings Access Control WPS Schedule |
| Power Supply | 9V DC/0.8A |
| Button | RST/WPS Button |
| LED Indicator | 1*Power, 1*CPU, 1*Wireless, 1*WAN, 4*LAN |
| Antenna | 2*11dBi Detachable Antennas (2*5dBi old model for Thailand) |
| Wireless Standards | IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
| RF Frequency | 2.4~2.4835GHz |
| Data Rate | 802.11n: Up to 300Mbps 802.11g: Up to 54Mbps (dynamic) 802.11b: Up to11Mbps (dynamic) |
| Wireless Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES) |
| Reception Sensitivity | 270M: -61 [email protected]% PER 135M: -65 [email protected]% PER 54M: -68 [email protected]% PER 11M: -85 [email protected]% PER 6M: -88 [email protected]% PER 1M: -90 [email protected]% PER |
| Environment | Operating Temperature: 0℃~55℃ (32°F~131°F) Storage Temperature: -20~65℃ (-4°F~149°F) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~95% non-condensing |
| Warranty | 1 Year Brand Warranty. |
