Description
| Model Name | ASUS TUF Dash F15 |
| Model | FX517ZE-HF144W |
| Color | Off Black |
| Dimension (W x D x H) | 35.4 x 25.1 x 1.99 ~ 2.07 cm |
| Weight | 2.00 Kg |
| Processor | 12th Gen Intel® Core™ i7-12650H Processor 2.3 GHz (24M Cache, up to 4.7 GHz, 10 cores: 6 P-cores and 4 E-cores) |
| Chipset | N/A |
| Discrete/Optimus | MUX Switch + Optimus |
| Graphic | NVIDIA® GeForce RTX™ 3050 Ti Laptop GPU |
| Graphic Wattage | 1535MHz* at 75W (1485MHz Boost Clock+50MHz OC, 60W+15W Dynamic Boost) |
| Graphic Memory | 4GB GDDR6 |
| IGPU | Intel® Iris Xᵉ Graphics |
| Panel Size | 15.6-inch |
| Resolution | FHD (1920 x 1080) 16:9 |
| Refresh Rate | 300Hz |
| Viewing Angle | 85/85/85/85 |
| Panel Tech | IPS-level |
| Brightness | 300 |
| Contrast | 1000:1 |
| NTSC % | 72% |
| SRGB % | 100% |
| Adobe % | 75.35% |
| Anti glare | Anti-glare display |
| Adaptive-Sync technology | Adaptive-Sync |
| Pantone | N/A |
| Support Dolby Vision HDR | N/A |
| On board memory | N/A |
| DIMM Memory | 8GB DDR5-4800 SO-DIMM *2 |
| Total System Memory | DDR5 16GB |
| Memory Slot | 2x SO-DIMM slots |
| Memory Max. | 32GB |
| Multi-channel memory technology | Support dual channel memory |
| System Storage | 512GB PCIe® 3.0 NVMe™ M.2 SSD |
| M.2 slots support either SATA or NVMe | 2 |
| M.2 SSD Support List | support PCIE Gen4x4 & Gen3x4 |
| Expansion Slot (includes used) | 2x DDR5 SO-DIMM slots |
| LAN | 10/100/1000 Mbps |
| Wi-Fi/Bluetooth | Wi-Fi 6(802.11ax) (Dual band) 2*2 + Bluetooth® 5.2 (*Bluetooth® version may change with OS version different.) |
| I/O Ports | “1x RJ45 LAN port 1x Thunderbolt™ 4 support DisplayPort™ 1x USB 3.2 Gen 2 Type-C support DisplayPort™ / power delivery / G-SYNC 2x USB 3.2 Gen 1 Type-A” |
| Display output | 1x HDMI 2.1 TMDS |
| Audio | 1x 3.5mm Combo Audio Jack |
| Webcam | 720P HD camera |
| Mic | Built-in array microphone |
| Keyboard Type | Backlit Chiclet Keyboard Single Light |
| NumberPad | N/A |
| Aura Sync | Yes |
| Speakers | 2-speaker system |
| Audio Tech | AI noise-canceling technology Dolby Atmos Hi-Res certification |
| Operating System | Windows 11 Home |
| Antivirus | MCAFEE_30D |
| Xbox Game Pass | Xbox Game Pass Ultimate_1 month (*Terms and exclusions apply. Offer only available in eligible markets for Xbox Game Pass Ultimate. Eligible markets are determined at activation. Game catalog varies by region, device, and time.) |
| Security | Kensington Security Slot™ Trusted Platform Module (Firmware TPM) |
| Battery | 76WHrs, 4S1P, 4-cell Li-ion |
| Power | ø6.0, 180W AC Adapter, Output: 20V DC, 9A, 180W, Input: 100~240V AC, 50/60Hz universal |
| Bundled Peripherals | TUF Gaming backpack |
| Warranty | 2 Years Brand Warranty |
