Description
| Antenna | Internal dBi antenna x 6 for Wi-Fi Bluetooth antenna x1 |
| Button | Power Switch |
| Color | Black |
| Coverage | Large homes |
| Data Rate | 802.11a : 6,9,12,18,24,36,48,54 Mbps 802.11b : 1, 2, 5.5, 11 Mbps 802.11g : 6,9,12,18,24,36,48,54 Mbps 802.11n 256QAM : up to 400 Mbps 802.11ac : up to 867 Mbps |
| Dimensions | 270 x 75 x 75 ~ mm (WxDxH) (Without Bezel) |
| Encryption | WPA2-Personal, WPA-Personal, WPA-Enterprise , WPA2-Enterprise |
| Features | Router app MU-MIMO Traffic Analyzer SmartQoS – WMM – User definable rules for IP/MAC/Port – Upload and download bandwidth management – ACK/SYN/FIN/RST/ICMP with highest priority AiProtection Parental Control Guest Network |
| Memory | 256 MB Flash 512 MB RAM |
| Operating Frequency | 2.4G Hz, 5 GHz-1, 5 GHz-2 |
| Operation mode | Wireless router mode Range extender mode Access point mode |
| OS Support | Windows® 10 Windows® 10 64-bit Windows® 8.1 Windows® 8 Windows® 7 Please update your BIOS and drivers to the latest version to support Windows 7 Windows® Vista Windows® 2000 Windows® ME Windows® XP Windows® Server 2003 Windows® Server 2008 Windows® Server 2008 R2 Windows® Server 2012 Windows® Server 2012 R2 Mac OS X 10.1 Mac OS X 10.4 Mac OS X 10.5 Mac OS X 10.6 Mac OS X 10.7 Mac OS X 10.8 |
| Ports | RJ45 for 1Gbps BaseT for WAN x 1, RJ45 for 1Gbps BaseT for LAN x 1 |
| Power Supply | AC Input : 110V~240V(50~60Hz) DC Output : 19 V with max. 2.37 A current |
| Product Segment | AC2200 ultimate AC performance : 400+867+867 Mbps |
| Product Weight (g) | 975 g |
| Transmit/Receive | 2.4 GHz 2 x 2 5 GHz-1 2 x 2 5 GHz-2 2 x 2 |
| WAN | Internet connection type : Automatic IP, Static IP, PPPoE(MPPE supported), PPTP, L2TP |
| Network Standard | IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Warranty | 2 Years Replacment. |
